PERFORMANCE ADVANTAGES
• Modified Imidazole for low temperature and quick cure.
• Can be used as a sole curing agent or as a DICY accelerator.
• Long latency.
APPLICATIONS
• Prepreg for composite.
• 1 K structural adhesives.
• Potting / Encapsulation in electrical and electronic application
STORAGE LIFE
At least 24 months from the date of manufacture in the original sealed container at ambient temperature. Store away from heat and excessive humidity in tightly closed containers.
HANDLING PRECAUTIONS
Refer to the Material Safety Data Sheet for Sunmide LH-210 curing agent
| TYPICAL PROPERTIES | |
| Appearance | Light Yellow Powder |
| Softening point (°C) | 135 |
| Particle size (um, D50) | 5.8 |
| Particle size (um, D90) | 11.2 |
| Specific Gravity @ 25°C | 1.120 |
| Recommended use level* (phr, EEW=190) | 10-25 |
* : sole cure agent
| TYPICAL FORMULATION (Sole cure) | |
| Epikote 828 (EEW=190) | 100 |
| Sunmide LH-210 | 10-25 |
| Fumed Silica | 1 |
| TYPICAL FORMULATION (Accelerator) | |
| Epikote 828 (EEW=190) | 100 |
| Dicyanex 1400B (DICY) | 6 |
| Sunmide LH-210 | 1-5 |
| Fumed Silica | 1 |
| TYPICAL PERFORMANCE* | |
| Latency (at 25C, double initial viscosity) | |
| 10 phr | > 3 months |
| 15 phr | 3 months |
| 20 phr | 6 weeks |
| 25 phr | 3 weeks |
| Lap Shear Strength (MPa) | |
| 10 phr | 19.6 |
| 15 phr | 17.0 |
| 20 phr | 18.0 |
| 25 phr | 18.5 |
* Formulation : Epikote 828 / Sunmide LH-210 = 100 / 10-25 Curing schedule for LSS : 150C for 1 hr
